Product Description
WANDFLUH MVPPM22-200-G24/WD-HB4.5
The WANDFLUH MVPPM22-200-G24/WD-HB4.5 is a high-performance, direct-operated proportional pressure reducing valve of the spool type. Designed for subplate mounting according to the ISO 4401-03 standard (NG6), this valve provides precise and continuous control of pressure in hydraulic systems. It is equipped with a 24V DC solenoid featuring integrated digital electronics (on-board amplifier), ensuring excellent dynamic response, low hysteresis, and high repeatability. The robust construction makes it ideal for demanding industrial applications where reliable and accurate pressure regulation is critical.
Technical Specifications:
- Type: Direct operated proportional pressure reducing valve, spool type
- Mounting: Subplate mounting ISO 4401-03 (NG6, CETOP 3)
- Nominal Pressure: 200 bar (2900 PSI)
- Max. Operating Pressure (Port P): 350 bar (5075 PSI)
- Nominal Flow Rate: 20 l/min
- Solenoid Voltage: 24 VDC (G24)
- Electronics: Integrated digital amplifier (WD)
WANDFLUH MVPPM22-200-G24/WD-HB4.5
Discover the WANDFLUH MVPPM22-200-G24/WD-HB4.5, a direct-operated NG6 proportional pressure reducing valve. Features a 24V DC solenoid and integrated digital electronics for precise hydraulic pressure control up to 200 bar.
