Product Description
XINJE XD-E16X16YT-E
The XINJE XD-E16X16YT-E is a powerful and economical Programmable Logic Controller (PLC) from the XD series, designed for a wide range of industrial automation applications. It features a robust configuration of 16 digital inputs and 16 transistor outputs, making it suitable for controlling small to medium-sized machinery and processes. Equipped with an integrated Ethernet port, as well as RS232 and RS485 communication ports, this PLC offers excellent connectivity and networking capabilities. Its support for high-speed counters and pulse outputs makes it ideal for applications requiring precise motion control, such as positioning, packaging, and labeling systems.
Technical Specifications:
- Power Supply: AC 100~240V
- I/O Points: 16 digital inputs (DI), 16 transistor outputs (DO)
- Output Type: Transistor (NPN)
- Program Capacity: 256K Steps
- Communication Ports: 1x Ethernet, 1x RS232, 1x RS485
- High-Speed Pulse Output: 4 channels at 200KHz
- High-Speed Counter: 6 single-phase channels (up to 200KHz) or 3 AB-phase channels (up to 100KHz)
XINJE XD-E16X16YT-E
Discover the XINJE XD-E16X16YT-E, an economical PLC with 16 digital inputs, 16 transistor outputs, and a built-in Ethernet port. Ideal for industrial automation and machine control.
| Brand | XINJE |
|---|---|
| Model | XD-E16X16YT-E |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/xinje-xd-e16x16yt-e |
