Product Description
YASKAWA CIMR-VB4A0007BBA
The YASKAWA CIMR-VB4A0007BBA is a high-performance, compact AC microdrive from the renowned V1000 series. Designed for exceptional reliability and efficiency, this variable frequency drive (VFD) offers precise motor speed and torque control for a wide range of industrial applications. It features advanced open-loop vector control, providing excellent performance even at low speeds. The V1000 series is known for its user-friendly interface, easy setup, and robust construction, making the CIMR-VB4A0007BBA an ideal solution for optimizing motor performance, saving energy, and extending the life of mechanical systems.
Technical Specifications:
- Series: V1000
- Input Voltage: 3-Phase 380-480V AC (-15% to +10%), 50/60 Hz
- Max. Motor Output (Normal Duty): 3.0 kW
- Max. Motor Output (Heavy Duty): 2.2 kW
- Rated Output Current (Normal Duty): 7.2 A
- Rated Output Current (Heavy Duty): 5.5 A
- Enclosure Type: NEMA 1 / IP20
- Control Modes: V/f Control, Open Loop Vector, PM Open Loop Vector
YASKAWA CIMR-VB4A0007BBA
Yaskawa CIMR-VB4A0007BBA V1000 series AC drive, 3.0kW Normal Duty / 2.2kW Heavy Duty, for 380-480V 3-phase input. A compact and powerful variable frequency drive for precise motor control.
