Product Description
Yaskawa SGMGH-20A2B6D
The Yaskawa SGMGH-20A2B6D is a high-performance AC servo motor from the Sigma-II series, designed for demanding industrial automation tasks. As a medium-inertia motor, it delivers exceptional stability and high torque output, making it ideal for applications requiring rapid acceleration and precise control of large loads. It features a high-resolution 17-bit absolute encoder for accurate positioning feedback and is equipped with a 24 VDC holding brake for enhanced safety, securing the load in a power-off state. The SGMGH-20A2B6D is a robust and reliable solution for machine tools, robotics, and other high-power motion control systems.
Technical Specifications:
- Model: SGMGH-20A2B6D
- Motor Series: Sigma-II
- Rated Output: 2.0 kW
- Power Supply Voltage: 200 VAC
- Rated Speed: 1500 rpm
- Rated Torque: 12.7 N·m
- Encoder Type: 17-bit Absolute Encoder
- Brake: Equipped with 24 VDC Holding Brake
- Shaft End: Straight with key and tap
Yaskawa SGMGH-20A2B6D
Yaskawa SGMGH-20A2B6D AC Servo Motor, 2.0kW, 200V, 1500rpm. Features a 17-bit absolute encoder, medium inertia, and an integrated 24VDC holding brake for precise, high-torque motion control in demanding industrial applications.
