Product Description
YOKOGAWA F3WD64-3N WD64-3N
The Yokogawa F3WD64-3N is a high-density 64-point transistor output module designed for the FA-M3 Range-free Controller series. This source-type module provides reliable digital output signals for controlling a wide range of devices in industrial automation systems. It operates on a 12 to 24 V DC load voltage and features photocoupler isolation to protect the PLC’s internal circuitry from external electrical noise and surges. With its compact design and two 40-pin connectors, the F3WD64-3N is ideal for applications requiring a large number of output points in a limited space, ensuring efficient and precise control.
Technical Specifications:
- Module Type: 64-point Transistor Output Module (Source Type)
- Number of Outputs: 64 points (16 points/common, 4 commons)
- Rated Load Voltage: 12 to 24 V DC (+20%/-15%)
- Maximum Load Current: 0.1 A per point / 2.0 A per common
- Response Time: OFF to ON: 0.1 ms or less; ON to OFF: 0.5 ms or less
- External Connection: Two 40-pin connectors
- Isolation: Photocoupler isolation between output terminals and internal circuits
YOKOGAWA F3WD64-3N WD64-3N
Discover the Yokogawa F3WD64-3N, a reliable 64-point source-type transistor output module for the FA-M3 PLC series. Engineered for high-density industrial automation, it provides precise 12-24V DC control.
