Product Description
AB 100-C12KJ10
The Allen-Bradley 100-C12KJ10 is a 3-pole IEC contactor from the Bulletin 100-C series, designed for reliable switching of electrical loads, particularly motors. It is rated for 12 Amps (AC-3 at 400V) and features an electronically controlled 24V DC coil with a PLC interface, which allows for direct control from PLC outputs and offers reduced power consumption. This contactor includes one normally open (N.O.) front-mounted auxiliary contact for additional signaling or interlocking functions. Its compact design is suitable for both DIN rail and panel mounting, making it a versatile choice for various industrial control applications requiring efficient motor control or power switching.
Technical Specifications:
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Product Series: Bulletin 100-C
- Product Type: IEC Contactor
- Part Number: 100-C12KJ10
- Number of Poles: 3-Pole
- Rated Operational Current (AC-3, ≤ 440V): 12 A
- Rated Operational Power (AC-3, 400V): 5.5 kW
- Rated Operational Power (AC-3, 415V): 5.5 kW
- Rated Operational Power (AC-3, 440V): 5.5 kW
- Coil Type: Electronic with PLC Interface
- Coil Voltage: 24V DC
- Auxiliary Contacts: 1 Normally Open (N.O.) Front Mounted
- Mounting Type: DIN Rail (35mm) / Panel Mount
- Terminal Type: Screw Terminals
- Utilization Category: AC-1, AC-3
- Ambient Temperature Range (Operation): -25°C to +60°C (-13°F to +140°F)
AB 100-C12KJ10
Model：AB 100-C12KJ10
