Product Description
Allen-Bradley 1762-IF20F2
The Allen-Bradley 1762-IF20F2 is a MicroLogix 1200 expansion analog combination I/O module. It is designed to add analog input and output capabilities to MicroLogix 1100, 1200, and 1400 controllers. This versatile module features two differential analog inputs and two single-ended analog outputs, both configurable for either voltage or current signals. Its compact design allows for easy integration into existing systems, providing precise control and monitoring for a wide range of industrial automation applications that require analog signal processing.
Technical Specifications:
- Module Type: Analog Combination I/O Module
- Number of Inputs: 2 Differential (Voltage/Current selectable)
- Number of Outputs: 2 Single-ended (Voltage/Current selectable)
- Resolution: 12-bit (11 bits + sign)
- Input Signal Range: ±10V DC, 0-20 mA, 4-20 mA
- Output Signal Range: 0-10V DC, 0-20 mA, 4-20 mA
- Compatibility: MicroLogix 1100, 1200, and 1400 controllers
Allen-Bradley 1762-IF20F2
Allen-Bradley 1762-IF20F2 MicroLogix expansion module with 2 analog inputs and 2 analog outputs. Provides flexible voltage/current signal processing for PLC systems.
| Brand | Allen-Bradley |
|---|---|
| Model | 1762-IF20F2 |
| Category | Electrical |
