Product Description
Allen-Bradley 2198-E1004-ERS Servo Drive
The Allen-Bradley 2198-E1004-ERS is a highly efficient and versatile Kinetix 5100 single-axis EtherNet/IP servo drive, engineered to deliver scalable motion control for a wide range of industrial applications. Featuring a 2.4kW power rating, this drive comes equipped with integrated hardwired safety (Safe Torque Off) to ensure maximum protection for both operators and machinery. It is designed with flexible power capabilities, accommodating main inputs of 100-120V AC (single-phase) or 200-230V AC (single or three-phase). Capable of delivering a continuous output current of 2.6 Arms and a peak of 5.0 Arms, the 2198-E1004-ERS provides precise, reliable performance. Additionally, it includes dual Ethernet ports for seamless network integration, a USB port for quick configuration, and a comprehensive I/O connector.
Technical Specifications:
- Brand: Allen-Bradley
- Model Number: 2198-E1004-ERS (Kinetix 5100 Series)
- Power Rating: 2.4 kW
- Main Input Voltage: 100-120 Vac (1PH, 4.06 Arms) or 200-230 Vac (1/3PH, 4.75/2.84 Arms), 50/60Hz
- Control Input: 100-120 Vac / 200-230 Vac, 1PH, 0.34 Arms Max
- Output Voltage & Frequency: 0-230Vrms, 3-Phase, 0-160Hz
- Output Current: 2.6 Arms Continuous / 5.0 Arms Peak
- Safety Feature: Hardwired Safety
- Max Short Circuit Current: 960A
- Communication & Connectivity: EtherNet/IP Ports, USB Port, I/O Connector
Allen-Bradley 2198-E1004-ERS Servo Drive
Optimize your industrial motion control with the Allen-Bradley 2198-E1004-ERS Kinetix 5100 Servo Drive. This 2.4kW, single-axis EtherNet/IP drive features built-in hardwired safety, versatile 120V/230V AC input compatibility, and 2.6A continuous output for reliable, high-performance automation.
