Product Description
APPOLLO DB02.001
The APPOLLO DB02.001 is a high-performance analog driver card designed for the precise control of single solenoid proportional hydraulic valves. Engineered for installation within electrical cabinets, this driver card operates on a 24 VDC power supply and translates reference input signals into a controlled PWM current for the valve’s solenoid. It features on-board potentiometers for fine-tuning critical parameters such as bias, gain, and ramp times (both up and down), allowing for optimized performance and smooth operation in a wide range of industrial hydraulic applications. Its robust design ensures reliable and stable control, making it an essential component for systems requiring accurate hydraulic motion and pressure regulation.
Technical Specifications:
- Card Type: Analog driver for single solenoid proportional valves
- Power Supply: 24 VDC (-10% / +20%)
- Input Signal: Selectable differential voltage (±10V) or single-ended current (4-20mA)
- Output Control: Pulse Width Modulated (PWM) current to solenoid
- Adjustments: On-board potentiometers for Bias, Gain, Ramp Up, and Ramp Down
- Mounting: Standard DIN 43700 format for electrical cabinet mounting
APPOLLO DB02.001
Discover the APPOLLO DB02.001, a reliable analog driver card for precise control of single solenoid proportional hydraulic valves. Features adjustable gain, bias, and ramp settings for optimal system performance.
