Product Description
Danfoss 060L313466 Pressure Transmitter MBS 1700
The Danfoss 060L313466 is a high-quality pressure transmitter from the MBS 1700 series, designed for reliable and accurate pressure measurement in general industrial applications. It is specifically engineered for use in demanding environments, offering excellent vibration stability and a robust construction. This model converts the measured pressure into a standard 4 – 20 mA output signal, making it easy to integrate into various control systems. Its compact design and standardized connections ensure a straightforward installation process for applications involving air and water.
Technical Specifications:
- Type: MBS 1700
- Pressure Range: 0 – 10 bar
- Output Signal: 4 – 20 mA
- Pressure Connection: G 1/4 Male (EN 837)
- Electrical Connection: Plug EN 175301-803-A (DIN 43650-A)
- Supply Voltage: 10 – 30 V DC
- IP Rating: IP65

Danfoss 060L313466
Shop the Danfoss 060L313466 pressure transmitter. This MBS 1700 model features a 0-10 bar range, 4-20 mA output, and G 1/4 connection for reliable industrial pressure measurement.
