Product Description
ATOS DKZOR-A-173-L5 40/PE
The ATOS DKZOR-A-173-L5 40/PE is a high-performance, direct-operated proportional directional control valve designed for precise control in electrohydraulic systems. This valve, built to ISO 4401 size 10 (NG10) standards, offers superior dynamics and repeatability. It is supplied without an on-board driver, intended for use with a separate Atos electronic driver. The /PE option integrates a pressure and temperature transducer, providing advanced feedback for sophisticated closed-loop control and system monitoring. Its robust construction ensures reliability and a long service life in demanding industrial applications requiring accurate regulation of oil flow direction and rate.
Technical Specifications:
- Valve Type: Direct operated proportional directional valve
- Model Code: DKZOR-A-173-L5 40/PE
- Mounting Interface: ISO 4401 size 10 (CETOP 5 / NG10)
- Maximum Regulated Flow: 50 l/min
- Maximum Operating Pressure: 350 bar
- Configuration: 4-way, 3-position, center-closed spool (type 3)
- Driver: External driver required (Type ‘A’ – without on-board driver)
- Special Feature: /PE – Integrated pressure and temperature transducer
ATOS DKZOR-A-173-L5 40/PE
Buy the ATOS DKZOR-A-173-L5 40/PE, a high-performance NG10 proportional directional valve with an integrated pressure/temperature transducer for precise hydraulic control up to 350 bar.
