Product Description
AVENTICS 0820059161 TC15-5/3EC-DO-024DC-E-FORM_C-SGL
The AVENTICS 0820059161 is a high-performance directional control valve belonging to the TC15 series. This valve is configured as a 5/3 way valve with an Exhaust Center (EC) function, meaning in the neutral position, both cylinder ports are connected to the exhaust ports. It features double solenoid actuation (DO) operating on 24V DC power. Electrical connection is facilitated via an EN 175301-803 Form C connector. This model includes a single manual override (SGL) for manual operation or testing purposes. Designed for robust industrial pneumatic applications requiring reliable control and a defined mid-position state.
Technical Specifications:
- Manufacturer: AVENTICS (Emerson)
- Series: TC15
- Part Number: 0820059161
- Valve Type: Spool valve, direct actuated
- Function: 5/3 Way, Exhaust Center (EC)
- Actuation Type: Double Solenoid (DO)
- Operating Voltage: 24V DC
- Voltage Tolerance: +/- 10%
- Power Consumption: 2 W
- Electrical Connection: Plug, EN 175301-803, Form C
- Manual Override: Yes, Single (SGL), Latching
- Pneumatic Connection: G 1/4
- Nominal Flow Rate (Qn @ 6 bar, Δp=1 bar): 1350 l/min
- Operating Pressure Range: -0.95 bar to 10 bar
- Control Pressure Range: 3 bar to 10 bar
- Medium: Compressed Air (Filtered to 5 µm, oiled or unoiled)
- Ambient Temperature Range: -10 °C to +50 °C
- Medium Temperature Range: -10 °C to +50 °C
- Protection Class (with connector): IP65
- Materials: Housing (Polyamide, fiber-glass reinforced), Seals (Acrylonitrile butadiene rubber)
AVENTICS 0820059161 TC15-5/3EC-DO-024DC-E-FORM_C-SGL
Model:AVENTICS 0820059161 TC15-5/3EC-DO-024DC-E-FORM_C-SGL
| Brand | AVENTICS |
|---|---|
| Model | 0820059161 TC15-5/3EC-DO-024DC-E-FORM_C-SGL |
| Part No. | AVENTICS 0820059161 TC15-5/3EC-DO-024DC-E-FORM_C-SGL |
| Category | Hydraulic valves |
| Link | https://www.echuan-hydraulic.com/product/aventics-0820059161-tc15-5-3ec-do-024dc-e-form_c-sgl |
