Product Description
Balluff BIS013Z
The Balluff BIS013Z is a high-performance RFID processor unit designed for the BIS M series identification system. Operating at a high frequency of 13.56 MHz, this compact processor seamlessly connects a single RFID read/write head to a higher-level control system via its IO-Link interface. Housed in a robust, IP67-rated die-cast zinc enclosure, the BIS013Z is built to withstand harsh industrial environments, ensuring reliable data transfer for tracking, tracing, and quality control applications. Its standardized IO-Link connection simplifies integration, reduces wiring complexity, and provides advanced diagnostics, making it an ideal solution for modern automation systems.
Technical Specifications:
- Type: BIS M-400-045-001-07-S4
- Interface: IO-Link 1.1
- Operating Frequency: 13.56 MHz
- Number of Read/Write Head Connections: 1
- Operating Voltage: 10.8…30 V DC
- Enclosure Rating: IP67 (when connected)
- Housing Material: Zinc, die-cast
- Ambient Temperature: -25…70 °C
Balluff BIS013Z
Discover the Balluff BIS013Z, a robust and compact RFID processor for the BIS M series. It features a 13.56 MHz frequency and an IO-Link interface for easy integration into industrial identification and automation systems.
