Product Description
Bently 3500/62 Process Variable Detector
The Bently Nevada 3500/62 Process Variable Monitor is a six-channel module designed for use with the Bently Nevada 3500 Machinery Protection System. It accepts standard +4 to +20 mA current inputs or -10 Vdc to +10 Vdc voltage inputs, representing various process variables such as pressure, flow, temperature, and level. The module conditions these signals and compares them against user-programmable alarm setpoints. This functionality allows the 3500 system to drive alarms for comprehensive machinery protection, making the 3500/62 a critical component for monitoring non-vibration parameters in industrial applications.
Technical Specifications:
- Inputs: Six channels that accept +4 to +20 mA current inputs or -10 Vdc to +10 Vdc voltage inputs.
- Power Consumption: 7.7 watts, typical.
- Operating Temperature: -30 °C to +65 °C (-22 °F to +150 °F).
- Humidity: 95% non-condensing.
Bently 3500/62 Process Variable Detector
The Bently Nevada 3500/62 is a six-channel process variable monitor for the 3500 system, accepting 4-20 mA or +/-10 Vdc inputs to monitor parameters like pressure, flow, and temperature for complete machinery protection.
| Brand | Bently |
|---|---|
| Model | 3500/62 Process Variable Detector |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/bently-3500-62-process-variable-detector |
