Product Description
Danfoss 061B000366 3421-1DB04
The Danfoss 061B000366, part of the MBS 3000 series, is a compact and robust pressure transmitter designed for reliable performance in demanding industrial and hydraulic applications. It is engineered to deliver accurate pressure measurement even when exposed to harsh conditions such as shock, vibration, and significant temperature fluctuations. Featuring an enclosure and wetted parts made from acid-resistant stainless steel (AISI 316L), this transmitter offers excellent media compatibility and durability. Its standardized 4-20 mA output signal ensures seamless integration into various control systems, making it an ideal choice for monitoring pressure in pumps, compressors, pneumatics, and water treatment systems.
Technical Specifications:
- Type: MBS 3000
- Pressure Range: 0 – 40 bar (Gauge)
- Output Signal: 4 – 20 mA
- Pressure Connection Type: G 1/4 A (ISO 228-1)
- Electrical Connection: DIN 43650-A plug
- Supply Voltage: 10 – 30 V d.c.
- IP Rating: IP65

Danfoss 061B000366 3421-1DB04
Buy the Danfoss 061B000366 (MBS 3000) compact pressure transmitter. Features a 0-40 bar range, 4-20 mA output, and G 1/4 connection for reliable industrial and hydraulic pressure sensing.
