Product Description
Danfoss MBC5100 061B110566
The Danfoss MBC 5100 is a compact, block-type pressure switch designed for use in harsh industrial and marine environments. This model, 061B110566, is engineered to withstand severe conditions, offering high vibration resistance and a robust IP65 enclosure. It features a high-quality single-pole double-throw (SPDT) microswitch and is suitable for monitoring, alarm, and regulation systems in various applications, including engines, pumps, compressors, and gearboxes. The MBC 5100 series is renowned for its reliability and holds all major marine approvals, ensuring performance and safety in demanding settings.
Technical Specifications:
- Pressure Range: 25 to 250 bar
- Differential: 13 to 40 bar (Adjustable)
- Contact Function: SPDT (Single Pole Double Throw)
- Pressure Connection: G 1/4 Female
- Max. Working Pressure: 600 bar
- Electrical Connection: Pg 13.5
- Enclosure Rating: IP65
- Approvals: LR, DNV, GL, RINA, ABS, BV, NKK, PRS, KRS, CCS
Danfoss MBC5100 061B110566
Shop the Danfoss MBC5100 061B110566 block-type pressure switch. Features a 25-250 bar range, SPDT contact, G 1/4 connection, and IP65 rating. Ideal for robust marine and industrial applications.
