Product Description
Hamamatsu C10628-01
The Hamamatsu C10628-01, also known as the ORCA-Flash4.0 LT+, is a high-performance scientific CMOS (sCMOS) camera designed for a wide range of demanding low-light imaging applications. It features a Gen II sCMOS sensor that delivers a large field of view, exceptionally low read noise, high quantum efficiency, and fast frame rates. This camera is well-suited for various scientific research fields, including fluorescence microscopy, live cell imaging, super-resolution microscopy, and other applications requiring high sensitivity and speed. The ORCA-Flash4.0 LT+ provides an excellent balance of advanced imaging capabilities and accessibility for researchers.
Technical Specifications:
- Model Name: ORCA-Flash4.0 LT+
- Sensor Type: Front-illuminated Gen II sCMOS
- Effective Number of Pixels: 2048 (H) × 2048 (V)
- Pixel Size: 6.5 µm × 6.5 µm
- Effective Area: 13.312 mm (H) × 13.312 mm (V)
- Full Well Capacity (typical): 30000 electrons
- Maximum Frame Rate (Full Resolution): 30 frames/s (via Camera Link)
- Read Noise (Median, typical, at 30 frames/s): 0.7 electrons rms
- Read Noise (RMS, typical, at 30 frames/s): 1.0 electrons rms
- Quantum Efficiency (Peak, typical): >82 %
- Dynamic Range (typical): 30000:1
- Exposure Time: 10 µs to 30 s
- Cooling Method: Forced air cooling (Peltier cooling to +5 °C)
- Interface: Camera Link
- Lens Mount: C-mount
Hamamatsu C10628-01
Model:Hamamatsu C10628-01
