The Heidenhain UV130D, with ID number 824215-01, is a versatile and robust pulse shaper designed for industrial applications. Its primary function is to convert sinusoidal voltage signals (~11 µApp) from incremental encoders into high-quality square-wave signals (TTL or HTL). This unit features selectable interpolation, allowing for a significant increase in measurement resolution. Housed in a compact enclosure for top-hat rail mounting, the UV130D is ideal for integrating Heidenhain encoders with control systems that require square-wave inputs, ensuring reliable signal transmission and enhanced system accuracy.
