Product Description
Honeywell 3310G 16144B3A74
The Honeywell Model 3310G 16144B3A74 is a high-temperature pressure transducer engineered for exceptional accuracy and durability in demanding industrial environments. Featuring an all-welded stainless steel construction, this sensor is designed to operate reliably at temperatures up to 260 °C [500 °F]. It provides a stable, unamplified mV/V output, making it suitable for a wide variety of measurement systems. This particular model is configured for a gage pressure range of 0 to 10000 psi, making it an ideal solution for applications such as oil and gas exploration, engine test stands, and high-temperature process control.
Technical Specifications:
- Model Series: Model 33 High Temperature Pressure Transducer
- Pressure Range: 0 psi to 10000 psi
- Pressure Type: Gage
- Output: 3.0 mV/V nominal
- Accuracy: ±0.25 % BFSL (Best Fit Straight Line)
- Operating Temperature: -54 °C to 260 °C [-65 °F to 500 °F]
- Excitation: 10 Vdc
- Material (Wetted Parts): 17-4 PH Stainless Steel
Honeywell 3310G 16144B3A74
Honeywell 3310G 16144B3A74 high-temperature pressure transducer for reliable measurements up to 10000 psi. Features rugged, all-welded stainless steel construction for harsh industrial environments.
