Product Description
Honeywell DPT1000U1-B
The Honeywell DPT1000U1-B is a versatile and highly accurate differential pressure transmitter designed for demanding HVAC and building automation applications. It is engineered to measure static and differential pressure of air and other non-aggressive gases with precision. This device is ideal for monitoring air filters, fans, and VAV systems, ensuring optimal performance and energy efficiency in ventilation and air conditioning systems. Featuring multiple selectable pressure ranges and output signals (Voltage or Current) in a single unit, the DPT1000U1-B offers exceptional flexibility for various installation requirements. Its user-friendly interface with a backlit display and an auto-zero calibration function simplifies commissioning and maintenance, making it a reliable choice for facility managers and HVAC technicians.
Technical Specifications:
- Pressure Ranges: Selectable; -100…+100 Pa / 0…100 Pa / 0…250 Pa / 0…500 Pa / 0…1000 Pa
- Output Signal: Selectable; 0…10 Vdc or 4…20 mA
- Power Supply: 24 Vac/dc
- Accuracy: ±1.5% of selected range
- Display: Yes, backlit LCD
- Protection Class: IP54
Honeywell DPT1000U1-B
Honeywell DPT1000U1-B multi-range differential pressure transmitter for HVAC systems. Features selectable pressure ranges up to 1000 Pa, selectable 0-10V/4-20mA outputs, and a backlit display for precise air pressure and flow monitoring.
