Product Description
IFM AC1218
The IFM AC1218 is a robust AS-i ClassicLine AirBox module designed for the seamless integration and control of pneumatic components within an AS-i network. It features innovative quick mounting technology, utilizing piercing contacts for a fast and reliable connection to the AS-i flat cable without the need for tools. This module provides four digital inputs for sensor monitoring and four pneumatic outputs for controlling single solenoid valves. Housed in a durable IP67-rated enclosure, the AC1218 is built to withstand harsh industrial environments, making it an ideal solution for factory automation and process control applications requiring efficient pneumatic actuation.
Technical Specifications:
- Product designation: AS-i ClassicLine module with quick mounting technology
- Application: For connection of pneumatic modules
- Operating voltage: 26.5…31.6 V DC (AS-i) / 20…30 V DC (AUX)
- Inputs / Outputs: 4 digital inputs / 4 digital (pneumatic) outputs
- Output function: 4 x 1 (single solenoid valve)
- Connection: AS-i flat cable connection; M12 connector for I/O
- Degree of protection: IP67
- Ambient temperature: -25…70 °C
IFM AC1218
IFM AC1218 AS-i AirBox module for pneumatic control. Features 4 digital inputs, 4 pneumatic outputs, IP67 rating, and quick mounting technology for easy installation.
