Product Description

IMT W18RX-06L

The IMT W18RX-06L is a compact and efficient low-speed, high-torque (LSHT) orbital hydraulic motor from the W series. Designed for light-duty applications, this motor provides reliable and smooth operation. Its gerotor gear set design ensures high efficiency and a long service life, even under demanding conditions. The W18RX-06L is an excellent choice for a wide range of machinery, including agricultural equipment, conveyors, machine tools, and other mobile or industrial systems that require precise rotational power in a small package.

Technical Specifications:

  • Displacement: 18 cm³/rev (1.10 in³/rev)

  • Max. Continuous Pressure: 105 bar (1520 PSI)

  • Max. Continuous Torque: 30 Nm (265 lb-in)

  • Max. Continuous Speed: 1000 RPM

IMT W18RX-06L Description

IMT W18RX-06L

Discover the IMT W18RX-06L, a reliable 18cc LSHT orbital hydraulic motor. Featuring a 2-bolt rhomb flange and G 3/8″ ports, it’s ideal for light-duty industrial and mobile applications.
