Product Description
Lenze MCA 10I40-RS0B0-B14N-ST6S00N-R0SU Servo Motor
The Lenze MCA 10I40-RS0B0-B14N-ST6S00N-R0SU is a highly dynamic 3-phase synchronous servo motor designed for demanding industrial automation and motion control applications. Manufactured in Germany, this compact and robust motor delivers a rated power of 0.8 kW (1.1 HP) and a rated torque of 2.0 Nm, with a peak stall torque (Mo) of 2.3 Nm. Operating at a rated speed of 3950 r/min and a frequency of 140 Hz, it ensures precise, high-speed performance. Built for reliability in harsh industrial environments, it features an IP65 protection rating, class F insulation, and an integrated KTY temperature sensor for optimal thermal monitoring. The motor is also equipped with an RS feedback encoder for accurate positioning and meets strict international standards, including CE, EN60034, and cRUus certifications.
Technical Specifications:
- Brand: Lenze
- Model: MCA 10I40-RS0B0-B14N-ST6S00N-R0SU
- Motor Type: 3-Phase Synchronous Servo Motor (3~MOT)
- Rated Voltage: 390 V AC
- Rated Power: 0.8 kW (1.1 HP)
- Rated Torque: 2.0 Nm
- Peak Torque (Mo): 2.3 Nm
- Rated Current: 2.4 A
- Rated Speed: 3950 r/min
- Frequency: 140 Hz
- Power Factor (cos φ): 0.70
- Protection Class: IP 65
- Insulation Class: F
- Ambient Temperature (Ta): 40°C
- Feedback System: RS Encoder
- Temperature Sensor: KTY
- Certifications: cRUus (E210321), CE, EN60034
- Country of Origin: Made in Germany
Lenze MCA 10I40-RS0B0-B14N-ST6S00N-R0SU Servo Motor
Genuine Lenze MCA 10I40-RS0B0-B14N-ST6S00N-R0SU 3-phase synchronous servo motor. Features 0.8 kW power, 390V AC, 3950 RPM, IP65 protection, and an integrated RS feedback encoder. Engineered in Germany for high-precision industrial automation. Order today for reliable performance and fast shipping.
