Product Description
Leuze HT25C.XL/4P-M12
The Leuze HT25C.XL/4P-M12 is a high-performance diffuse reflection sensor from the 25C series, engineered for reliable object detection in challenging industrial applications. It features advanced background suppression technology, ensuring precise detection of objects regardless of color or surface texture, while effectively ignoring any background interference. With an extended operating range of up to 1.2 meters, this sensor offers exceptional flexibility for use in logistics, packaging, and material handling systems. The visible red light source simplifies alignment, and the robust M12 connector ensures a secure and straightforward installation. Housed in a durable PC-ABS enclosure with an IP67/IP69K rating, the HT25C.XL/4P-M12 is built to withstand harsh environments, including high-pressure washdowns.
Technical Specifications:
- Operating Principle: Diffuse reflection sensor with background suppression (HGA)
- Operating Range: 0.005 – 1.2 m (Against white 90%)
- Switching Output: PNP, Push-pull (Light/dark switching)
- Connection: M12 connector, 4-pin
Leuze HT25C.XL/4P-M12
Discover the Leuze HT25C.XL/4P-M12, a versatile diffuse sensor with reliable background suppression and an extended 1.2m range. Ideal for automation, it features a PNP output and a standard M12 connector for easy integration.
