Product Description

Meanwell NES-150-24

The Meanwell NES-150-24 is a highly reliable, 150W single-output enclosed type AC/DC switching power supply. It features a selectable AC input range (85-132VAC / 170-264VAC) and provides a stable 24V DC output. This model is designed for efficiency and durability, incorporating protections against short circuits, overload, over-voltage, and over-temperature. Cooled by free air convection, it operates efficiently without a fan, making it suitable for a wide range of industrial automation machinery, control systems, and electronic equipment where a dependable power source is critical.

Technical Specifications:

  • Model: NES-150-24

  • Output Voltage: 24V DC

  • Rated Current: 6.5A

  • Rated Power: 156W

  • Input Voltage Range: 85 ~ 132VAC / 170 ~ 264VAC (Selectable by switch)

  • Efficiency (Typ.): 88%

  • Protections: Short circuit / Overload / Over voltage / Over temperature

  • Dimensions (LxWxH): 199 x 98 x 38 mm

Meanwell NES-150-24 Description

Meanwell NES-150-24

Discover the Meanwell NES-150-24, a reliable 150W 24V 6.5A enclosed AC/DC switching power supply. Ideal for industrial control and automation applications, offering high efficiency and built-in protections.
