Product Description
NORGREN 9500295 18D Series Electro-Mechanical Pressure Switch
The NORGREN 9500295 is a high-performance electro-mechanical pressure switch from the proven 18D series. Designed for exceptional reliability and a long service life, it is ideal for monitoring pressure in pneumatic systems. This switch features a robust diaphragm design and a simple, adjustable set point, allowing for precise control. Its compact and durable construction makes it suitable for a wide range of industrial applications, operating effectively with both lubricated and non-lubricated compressed air. The change-over contact provides versatile switching options for various control circuits.
Technical Specifications:
- Manufacturer Series: 18D
- Part Number: 9500295
- Actuation Type: Diaphragm
- Pressure Setting Range: 0.5 to 8 bar (7 to 116 psi)
- Port Connection: G1/4
- Switching Function: Change-over (SPDT)
- Electrical Connection: Plug Connector to DIN EN 175301-803 Form A
- Maximum Voltage: 250V AC/DC
- Maximum Switching Current: 4A (resistive load)
- IP Rating: IP65 (with connector)
- Operating Temperature: -10°C to +80°C
- Operating Medium: Compressed air and neutral gases, filtered, lubricated or non-lubricated
- Body Material: Zinc Alloy
- Seal Material: NBR (Nitrile)
NORGREN 9500295
Model：NORGREN 9500295
| Brand | Norgren |
|---|---|
| Model | 9500295 |
| Part No. | NORGREN 9500295 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/norgren-9500295 |
