Product Description
Pilz PNOZ X2.7P Safety Relay
The Pilz PNOZ X2.7P is a versatile and reliable safety relay designed for monitoring safety functions such as E-STOP pushbuttons, safety gates, and light barriers. Part of the proven PNOZ X series, this compact unit ensures high safety standards in a wide range of industrial applications. It features dual-channel operation with detection of shorts across contacts, making it suitable for applications up to PL e of EN ISO 13849-1 and SIL CL 3 of IEC 62061. Its narrow 22.5 mm housing saves valuable cabinet space, while the LED indicators provide clear status diagnostics for power, input channels, and output switch state.
Technical Specifications:
- Supply Voltage: 24 VDC
- Safety Contacts: 2 N/O (Normally Open)
- Auxiliary Contacts: 1 N/C (Normally Closed)
- Terminal Type: Screw terminals
- Housing Width: 22.5 mm
- Safety Level: PL e (EN ISO 13849-1), SIL CL 3 (IEC 62061)
Pilz PNOZ X2.7P
Discover the Pilz PNOZ X2.7P, a compact 24VDC safety relay for reliable monitoring of E-STOP and safety gate applications. This unit provides 2 N/O safety contacts and meets the highest safety standards, including PL e and SIL 3.
