Product Description
Rexroth 4WE6D62/OFEG24N9K4/V R900903465
The Rexroth 4WE6D62/OFEG24N9K4/V is a high-performance, direct-operated directional spool valve with solenoid actuation. Designed for reliability and precision, this size 6 (NG6) valve controls the start, stop, and direction of fluid flow in hydraulic systems. This specific model features a ‘D’ spool configuration and operates with 24V DC solenoids. It is equipped with a detent (OF), which holds the spool in its last switched position without continuous power to the solenoid. The concealed manual override (N9) allows for operation during power loss, and FKM (Viton) seals provide compatibility with a wide range of hydraulic fluids and operating temperatures. It conforms to the CETOP 3 mounting pattern for easy integration into standard hydraulic manifolds.
Technical Specifications:
- Type: 4/2 Directional Spool Valve
- Model Code: 4WE6D62/OFEG24N9K4/V
- Size: NG6 (CETOP 3)
- Maximum Operating Pressure: 350 bar (5075 psi)
- Maximum Flow Rate: 80 l/min (21 GPM)
- Actuation: Solenoid-operated with detent (no spring return)
- Solenoid Voltage: 24V DC
- Electrical Connection: Connector to DIN EN 175301-803
- Seals: FKM (Viton)
Rexroth 4WE6D62/OFEG24N9K4/V R900903465
Buy the Rexroth 4WE6D62/OFEG24N9K4/V (R900903465) hydraulic directional valve. This NG6, 24V DC solenoid-operated valve features a detent and FKM seals for reliable performance in industrial hydraulic applications.
