Product Description
Rexroth DBW 30 B2-52/100 6EG24N9K4 R900922310
The Rexroth DBW 30 B2-52/100 is a high-performance, pilot-operated pressure relief valve designed to limit the operating pressure in a hydraulic system. This model features an integrated solenoid-actuated directional spool valve, allowing for the pressure to be electrically unloaded to a minimum setting. It is engineered for subplate mounting according to ISO 6264 standards, ensuring easy integration and replacement. Built for reliability and precise pressure control, this valve is ideal for applications requiring safe and efficient system pressure management with the flexibility of electrical unloading for functions like circuit start-up or emergency stops.
Technical Specifications:
- Type: Pilot-operated pressure relief valve with switching solenoid
- Model Code: DBW 30 B2-52/100 6EG24N9K4
- Component Series: 5X (52)
- Size: 30
- Mounting Pattern: ISO 6264-AR-08-2-A
- Pressure Adjustment Range: Up to 100 bar
- Maximum Flow: 650 L/min
- Solenoid Voltage: 24V DC
- Electrical Connection: Connector according to DIN EN 175301-803 without indicator light
Rexroth DBW 30 B2-52/100 6EG24N9K4 R900922310
Order the genuine Rexroth DBW 30 B2-52/100 6EG24N9K4 (R900922310) pilot-operated pressure relief valve. This size 30 valve provides precise pressure control up to 100 bar and features a 24V DC solenoid for electrical unloading.
