Product Description
Rexroth 4WRZE10E68-150-7X/6EG24N9ETK31/A1D3M R900700633
The Rexroth 4WRZE10E68-150-7X/6EG24N9ETK31/A1D3M is a high-performance, 2-stage proportional directional valve designed for precise closed-loop control applications. This size NG10 valve features electrical position feedback for the main spool and integrated electronics (OBE), ensuring excellent dynamic response and high accuracy. It directly controls the direction and magnitude of hydraulic fluid flow, making it ideal for demanding industrial systems requiring precise axis control. The valve is actuated by proportional solenoids and designed for subplate mounting according to ISO 4401 standards. Its robust construction and integrated digital electronics provide reliability and simplified system integration.
Technical Specifications:
- Type: 2-stage proportional directional valve with integrated electronics (OBE)
- Size: NG10 (CETOP 5)
- Max. Operating Pressure: Ports P, A, B: 350 bar | Port T: 210 bar
- Nominal Flow Rate: 150 L/min
- Supply Voltage: 24V DC
- Command Signal Interface: ±10 V
- Sealing Material: FKM (Viton)
- Mounting Pattern: ISO 4401-05-05-0-05
Rexroth 4WRZE1068-150-74/6EG24N9ETK31/A1D3M R900700633
Shop the Rexroth R900700633, a 4WRZE10 proportional directional valve, size NG10, with 150 L/min flow. Features 24V DC integrated electronics (OBE) and position feedback for precise hydraulic control.
