Product Description
Rexroth R91099186 A A10VSO 18 DFR1/31R-VPA12N00
The Bosch Rexroth A A10VSO 18 DFR1/31R-VPA12N00 is a high-performance axial piston variable pump with a swashplate design, engineered for open circuit hydraulic systems. Widely used in both mobile and industrial applications, this pump is recognized for its reliability, long service life, and low operating noise. It features a DFR1 pressure and flow compensator, which allows for precise and energy-efficient control of the hydraulic system by matching output to demand. Its robust construction, excellent suction characteristics, and through-drive capability for mounting additional pumps make it a versatile and dependable choice for demanding hydraulic applications.
Technical Specifications:
- Model Code: A A10VSO 18 DFR1/31R-VPA12N00
- Part Number: R91099186
- Pump Type: Axial Piston Variable Pump (Swashplate design)
- Displacement: 18 cm³ per revolution
- Control Device: DFR1 – Pressure and flow compensator
- Nominal Pressure: 280 bar (4050 psi)
- Peak Pressure: 350 bar (5100 psi)
- Direction of Rotation: Clockwise (viewed from shaft end)
- Series: 31
- Drive Shaft: Splined shaft SAE J744 16-4, 9T
- Sealing Material: FKM (Viton)
- Mounting Flange: SAE 2-bolt
- Circuit Type: Open Circuit
Rexroth R91099186 A A10VSO 18 DFR1/31R-VPA12N00
Model:Rexroth R91099186 A A10VSO 18 DFR1/31R-VPA12N00
