Product Description
RITTAL W2E200-HH38-07 SK 3326107
The Rittal SK 3326107 is a high-performance axial fan designed for efficient climate control in electrical enclosures and control cabinets. This robust fan unit is engineered to dissipate heat loads, ensuring the optimal operating temperature for sensitive electronic components and preventing equipment failure due to overheating. Manufactured with a durable sheet steel housing, it is built for reliability in demanding industrial environments. The fan’s design facilitates straightforward installation and provides significant air throughput to maintain a stable internal climate within the enclosure.
Technical Specifications:
- Rated operating voltage: 230 V, 1~, 50 Hz/60 Hz
- Air throughput (unimpeded air flow): 800 m³/h at 50 Hz, 920 m³/h at 60 Hz
- Power consumption Pel: 80 W at 50 Hz, 90 W at 60 Hz
- Dimensions (W x H x D): 255 x 255 x 105 mm
- Rated current max.: 0.35 A at 50 Hz, 0.4 A at 60 Hz
- Operating temperature range: -10 °C to 55 °C
- Noise level: 51 dB(A) at 50 Hz, 55 dB(A) at 60 Hz
RITTAL W2E200-HH38-07 SK 3326107
Shop the Rittal SK 3326107 (W2E200-HH38-07) axial fan, a reliable 230V solution for enclosure climate control, delivering high air throughput up to 920 m³/h for effective heat dissipation.
