Product Description
SAGINOMIYA FNS-C106WKQ
The SAGINOMIYA FNS-C106WKQ is a high-reliability flow switch designed to detect the flow of liquid in pipelines. It is commonly used in HVAC, refrigeration, and industrial process systems to protect equipment such as compressors, pumps, and chillers from damage caused by a lack of fluid flow. This switch operates an SPDT contact when the flow rate either exceeds or drops below the adjustable setpoint. Its robust construction ensures long-lasting performance in demanding environments, making it an essential safety and control component for water, ethylene glycol, and other non-corrosive fluid applications.
Technical Specifications:
- Model: FNS-C106WKQ
- Pipe Connection: 1″ NPT Male
- Max. Fluid Pressure: 1 MPa (10.2 kgf/cm²)
- Fluid Temperature Range: -20 to 120°C
- Switch Function: SPDT (Single Pole Double Throw)
- Electrical Rating: 15A at 125/250V AC
- Enclosure: Watertight (IP44 equivalent)
SAGLNOMIYA FNS-C106WKQ
Order the genuine Saginomiya FNS-C106WKQ flow switch for reliable liquid flow detection and equipment protection in HVAC and industrial systems. Features a 1″ NPT connection and SPDT switch.
