Product Description
Schneider Electric SH30552P12F2000 Servo Motor
The Schneider Electric SH30552P12F2000 is a high-performance synchronous servo motor from the Lexium SH3 series, designed for demanding automation and motion control applications. Engineered in Germany, this compact and powerful motor delivers a rated power of 0.6 kW and a continuous torque of 0.8 Nm, achieving a high rated speed of 8000 rpm. It features an integrated 24V holding brake for enhanced safety and position control, along with a Thermo PTC sensor for thermal protection. With its robust construction and IP50/IP65 protection rating, the SH30552P12F2000 ensures reliable operation in various industrial environments, making it an ideal choice for robotics, packaging machinery, and material handling systems.
Technical Specifications:
- Model: SH30552P12F2000
- Product Series: Lexium SH3
- Rated Power (PN): 0.6 kW
- Rated Voltage (UN): 480 Vrms
- Rated Speed (nN): 8000 rpm
- Maximum Speed (nmax): 9000 rpm
- Rated Torque (M0): 0.8 Nm
- Rated Current (I0): 1.2 Arms
- Protection Class (IP): IP50 (IP65 on shaft)
- Thermal Protection: Thermo PTC sensor
- Integrated Brake: Yes, 24 VDC with 0.8 Nm holding torque
Schneider Electric SH30552P12F2000 Servo Motor
Discover the Schneider Electric SH30552P12F2000, a high-speed Lexium SH3 servo motor offering 0.6 kW power, 8000 rpm rated speed, and an integrated 24V brake. Perfect for precision automation and dynamic motion control tasks.
| Brand | Schneider Electric |
|---|---|
| Model | SH30552P12F2000 |
| Part No. | 710609338299 |
| Category | Servo motors |
| Link | https://www.echuan-hydraulic.com/product/schneider-electric-sh30552p12f2000-servo-motor |
