Product Description
SUN LPDC-XHN
The SUN LPDC-XHN is a high-performance, pilot-operated, proportional relief valve designed to limit pressure in a hydraulic circuit. As a normally closed, poppet-type cartridge valve, it provides continuous and precise pressure control in response to a variable electrical input signal. This valve is engineered for excellent stability and low leakage, making it ideal for protecting hydraulic components from overpressure. Its proportional nature allows for dynamic pressure adjustments, suiting a wide range of industrial and mobile applications where accurate pressure management is critical. The LPDC-XHN is designed for installation in a standard Sun T-11A cavity.
Technical Specifications:
- Cavity: T-11A
- Capacity: 40 gpm (150 L/min)
- Maximum Operating Pressure: 5000 psi (350 bar)
- Maximum Relief Setting (H Range): 4000 psi (280 bar)
- Control Pilot Flow: 0.11 – 0.19 gpm (0,4 – 0,7 L/min)
- Reseat: >90% of cracking pressure
- Seal Material: Buna-N (Nitrile)
- Compatible Coils: 740 Series
- Valve Hex Size: 1 1/8 in.
- Valve Installation Torque: 45 – 50 lbf ft (60 – 70 Nm)
SUN LPDC-XHN
Model：SUN LPDC-XHN
| Brand | SUN |
|---|---|
| Model | LPDC-XHN |
| Part No. | SUN LPDC-XHN |
| Category | Hydraulic valves |
