Product Description

TIVAL FF 4 – 4 GL DAH Pressure Switch

The TIVAL FF 4 – 4 GL DAH is a robust and reliable pressure switch designed for precise pressure monitoring and control in a wide range of applications, including pumps and compressors. Engineered in Germany, this switch ensures dependable performance with an adjustable pressure range from 0.22 to 4 bar. Its durable construction allows for a maximum operating pressure of 24 bar, making it suitable for demanding industrial environments. The FF 4 series is a trusted solution for automating fluid and air pressure systems, providing accurate switching for single-phase motors up to 0.55kW.

Technical Specifications:

  • Model: FF 4 – 4 GL DAH
  • Part Number: 1010020
  • Adjustable Pressure Range: 0.22 … 4 bar
  • Max. Operating Pressure: 24 bar
  • Max. Proof Pressure: 40 bar
  • Electrical Rating: 6A 230V~ AC1 / 4(4)A 400V~
  • Motor Suitability: 0.55kW 1-phase motor
  • Connection: 3/8 inch internal thread

TIVAL FF 4 - 4 GL DAH Pressure Switch Description

TIVAL FF 4 – 4 GL DAH Pressure Switch

Shop the TIVAL FF 4 – 4 GL DAH pressure switch (Part No. 1010020) for reliable pressure control. Features an adjustable range of 0.22-4 bar, 24 bar max operating pressure, and a 3/8″ connection. Ideal for pumps and compressors.
