Product Description
TURCK PS016V-401-LI2UPN8X-H1141 Pressure Switch
The TURCK PS016V-401-LI2UPN8X-H1141 is a high-performance electronic pressure switch from the PS+ series, designed for reliable monitoring of relative pressure in industrial hydraulic and pneumatic systems. It features a robust stainless steel housing (IP67/IP69K) and a user-friendly, 180° rotatable 4-digit display for clear readability from any orientation. With integrated IO-Link communication, this sensor allows for simple parameterization, diagnostics, and flexible configuration of its two switching outputs or a combination of switching and analog outputs. This versatility makes it an ideal solution for a wide range of demanding automation tasks.
Technical Specifications:
- Model: PS016V-401-LI2UPN8X-H1141
- ID Number: 6832579
- Pressure Range: 0…16 bar (relative) / 0…232 psi
- Output Function: IO-Link / 2 x PNP/NPN switching outputs, or 1 x switching and 1 x analog output (4…20 mA / 0…10 V)
- Process Connection: G 1/4″ male thread (DIN 3852-E)
- Electrical Connection: M12 x 1 male connector, 4-pin
- Operating Voltage: 18…30 VDC
- Protection Class: IP67 / IP69K
TURCK PS016V-401-LI2UPN8X-H1141 Pressure Switch
Shop the TURCK PS016V-401-LI2UPN8X-H1141 (6832579) electronic pressure switch. This robust sensor features a 0-16 bar range, IO-Link communication, a rotatable display, and configurable outputs, ideal for industrial hydraulic and pneumatic applications.
| Brand | TURCK |
|---|---|
| Model | PS016V-401-LI2UPN8X-H1141 |
| Part No. | 964497797123 |
| Category | Hydraulic parts |
