Product Description
WAGO 787-1664/0000-0011
The WAGO 787-1664/0000-0011 is a high-performance switched-mode power supply from the EPSITRON® PRO Power 2 series, engineered for demanding industrial applications. This robust 3-phase unit delivers a stable and adjustable 24 VDC output at 40 A, providing a total power of 960 W. It features exceptional efficiency of up to 96%, minimizing energy loss and heat generation within the control cabinet. Equipped with innovative TopBoost and PowerBoost functions, it can reliably handle high inrush currents and temporary peak loads, ensuring system stability. The integrated line monitor and signaling contacts provide advanced diagnostic capabilities, making it an ideal choice for critical systems requiring high reliability and continuous operation.
Technical Specifications:
- Input Voltage Range: 3 x AC 380 … 480 V; 2 x AC 380 … 480 V; DC 450 … 745 V
- Output Voltage: DC 24 V (adjustable 24 … 28 V)
- Nominal Output Current: 40 A
- Nominal Output Power: 960 W
- Efficiency (typ.): 96 %
- Special Features: TopBoost, PowerBoost, Line Monitor function
- Mounting Type: DIN-35 rail
- Protection Type: IP20
WAGO 787-1664/0000-0011
Order the WAGO 787-1664/0000-0011, a reliable 3-phase EPSITRON® PRO Power 2 power supply. This DIN-rail mountable unit provides 24V DC at 40A (960W) with high efficiency and advanced features like TopBoost and PowerBoost for industrial automation.
| Brand | Wago |
|---|---|
| Model | 787-1664/0000-0011 |
| Category | Electrical |
| Link | https://www.echuan-hydraulic.com/product/wago-787-1664-0000-0011 |
