Product Description
Wenglor UF55PD3S141 Ultrasonic Sensor
The Wenglor UF55PD3S141 is a high-performance ultrasonic sensor designed for reliable object detection in a variety of industrial applications. Housed in a compact M18 threaded brass enclosure, this sensor operates on the principle of sound propagation, allowing it to accurately detect objects regardless of their color, transparency, or surface texture. It features two antivalent PNP switching outputs and offers a versatile working range from 30 to 400 mm. The sensor can be easily configured via a teach-in button, and its robust IP67 protection rating ensures dependable operation even in harsh environments.
Technical Specifications:
- Working Range: 30…400 mm
- Supply Voltage: 10…30 V DC
- Switching Output: 2 x PNP NO/NC (antivalent)
- Housing: M18x1, Brass, nickel-plated
- Connection: M12 x 1; 4-pin Connector
- Protection Class: IP67
- Response Time: 47 ms

Wenglor UF55PD3S141
Buy the Wenglor UF55PD3S141 Ultrasonic Sensor. This M18 sensor features a 30-400mm detection range, two PNP switching outputs, and a rugged IP67-rated brass housing for reliable industrial object detection.
