Product Description

Wieland 81.020.0000.0

The Wieland 81.020.0000.0 is a female connector from the renowned gesis® CON GST18i3 series, designed for fast, safe, and flexible electrical installations. This 3-pole, black connector features a reliable screw-type connection, making it ideal for a wide range of applications in building automation, lighting systems, and industrial environments. Its robust construction ensures a durable and secure connection, while the coding system prevents mismating. This component is an essential part of the gesis® pluggable installation system, which significantly reduces on-site installation time and labor costs.

Technical Specifications:

  • Model: GST18I3F B2 ZR1 SW

  • Rated Voltage: 250 V

  • Rated Current: 20 A

  • Number of Poles: 3 (L, N, PE)

  • Connection Type: Screw connection

  • Wire Cross-section: 0.75 mm² – 2.5 mm²

  • Cable Diameter: 7.8 – 10.3 mm

  • Color: Black

Wieland 81.020.0000.0 Description

Wieland 81.020.0000.0

Order the Wieland 81.020.0000.0 GST18i3F female connector. This 3-pole, 20A plug features a secure screw connection and is ideal for quick and reliable electrical installations in building and lighting applications.
