Product Description

Balluff BIS0057

The Balluff BIS0057, also known as the BIS M-400-045-002-07-S4, is a high-performance RFID processor designed for industrial identification tasks. As part of the BIS M series, this compact processor operates at a frequency of 13.56 MHz and utilizes the IO-Link 1.1 interface for seamless integration into modern automation systems. Its rugged die-cast zinc housing and IP67 protection rating ensure reliable operation even in harsh industrial environments. This processor is ideal for applications requiring robust and efficient data acquisition, such as tool identification, material flow control, and production tracking.

Technical Specifications:

  • Part Number: BIS M-400-045-002-07-S4

  • Interface: IO-Link 1.1

  • Operating Frequency: 13.56 MHz

  • Operating Voltage: 10…30 V DC

  • Housing Material: Zinc, Die-cast

  • Connection: M12x1-Male, 4-pin, A-coded

  • IP Rating: IP67 (when connected)

  • Ambient Temperature: -25…70 °C

Balluff BIS0057 Description

Balluff BIS0057

Discover the Balluff BIS0057 (BIS M-400), a robust IP67 RFID processor with an IO-Link interface for reliable 13.56 MHz industrial identification and data tracking in automated systems.
