Product Description
Beckhoff CX9020-0111
The Beckhoff CX9020-0111 is a compact, high-performance DIN rail-mountable Embedded PC designed for a wide range of automation tasks. It features a powerful 1 GHz ARM Cortex™-A8 processor, making it suitable for demanding PLC, motion control, and visualization applications. The CX9020-0111 serves as a robust control system in a space-saving housing, offering direct connectivity to Beckhoff’s extensive line of Bus Terminals (K-bus) or EtherCAT Terminals (E-bus). This specific model comes pre-installed with the TwinCAT 3 automation software runtime, providing a comprehensive platform for engineering and control. With multiple interfaces including two switched Ethernet ports, USB, and a DVI-D connection, it offers excellent connectivity and flexibility for modern industrial environments.
Technical Specifications:
- Processor: ARM Cortex™-A8, 1 GHz
- Main Memory: 1 GB DDR3 RAM
- Storage: MicroSD card slot (512 MB card included with the basic configuration)
- Interfaces: 2 x RJ45 10/100 Mbit/s (switched), 4 x USB 2.0, 1 x DVI-D
- Operating System: Microsoft Windows Embedded Compact 7
- Control Software: TwinCAT 3 runtime (XAR)
- Power Supply: 24 V DC (-15 %/+20 %)
- Protection Class: IP20
Beckhoff CX9020-0111
The Beckhoff CX9020-0111 is a compact, DIN rail Embedded PC with a 1 GHz ARM Cortex™-A8 processor and TwinCAT 3 runtime, designed for advanced PLC and motion control applications.
