Product Description
Beckhoff KL2808
The Beckhoff KL2808 is a high-density digital output terminal designed for the Beckhoff Bus Terminal system. It provides eight independent channels for switching 24 V DC loads up to 0.5 A. This terminal is engineered for reliability in industrial environments, featuring short-circuit proof outputs and reverse voltage protection. Each channel has an integrated LED for clear status indication, which simplifies diagnostics and commissioning processes. The KL2808 is an efficient and compact solution for controlling a wide range of actuators, such as solenoid valves, contactors, and signal lamps.
Technical Specifications:
- Number of outputs: 8
- Nominal voltage: 24 V DC (-15 %/+20 %)
- Max. output current: 0.5 A per channel (short-circuit proof)
- Current consumption K-bus: typ. 18 mA
- Bit width in the process image: 8 outputs
- Electrical isolation: 500 V (K-bus/field potential)
Beckhoff KL2808
Beckhoff KL2808 8-channel digital output terminal, 24V DC, 0.5A per channel. A reliable, short-circuit proof I/O module for industrial automation and control systems.
