Product Description
CKD AG3X Series Direct Acting 3-Port Solenoid Valve
The CKD AG3X series represents a line of highly versatile and compact direct-acting 3-port solenoid valves designed for a wide range of fluid control applications. These valves feature a universal porting design, allowing them to be configured as Normally Closed (NC), Normally Open (NO), or as a diverter/selector valve, providing exceptional flexibility in system design. Available in various body and seal materials, the AG3X series is compatible with numerous fluids, including air, inert gas, water, and oil. Its robust construction and reliable performance make it an ideal choice for automation, pneumatic systems, and general-purpose fluid management tasks where precise control is essential.
Technical Specifications:
- Valve Type: Direct Acting 3-Port Solenoid Valve (Universal Type)
- Port Size: Rc1/8, Rc1/4
- Orifice Diameter: ø1.5 mm, ø2.3 mm, ø3.5 mm
- Fluid Compatibility: Air, Inert Gas, Low Vacuum, Water, Kerosene, Oil (model dependent)
- Body/Seal Material Options: Body (Brass, Stainless Steel), Seal (NBR, FKM, EPDM)
- Maximum Operating Pressure: Varies by orifice and fluid (e.g., up to 1.0 MPa for Air)
