Product Description
Danfoss MBC5100 1411-1DB04 061B012766
The Danfoss MBC 5100 is a compact, block-type pressure switch designed for reliable performance in harsh industrial and marine environments. This model is engineered to withstand severe conditions, offering high vibration resistance and robust construction. It features a fixed, low differential to ensure accurate monitoring and control of pressure for air, gas, and liquid systems. With its SPDT contact system and IP65 enclosure rating, the MBC 5100 provides a dependable solution for a wide range of applications, and it holds major marine approvals, making it suitable for use on ships and offshore installations.
Technical Specifications:
- Model: MBC5100, Type 1411-1DB04
- Pressure Range: -0.2 to 4 bar
- Differential: 0.2 bar (Fixed)
- Contact Function: SPDT (Single Pole Double Throw)
- Pressure Connection: G 1/4 A (ISO 228/1)
- Electrical Connection: DIN 43650-A, Pg 11
- Enclosure Rating: IP65
- Approvals: LR, DNV GL, CCS, RMRS, and others

Danfoss MBC5100 1411-1DB04 061B012766
Buy the Danfoss MBC5100 1411-1DB04 (061B012766) block pressure switch. Features a -0.2 to 4 bar range, SPDT contacts, IP65 enclosure, and marine approvals. Ideal for robust industrial and marine applications.
