Product Description
Festo MSFW-230-50/60
The Festo MSFW-230-50/60 is a standard solenoid coil designed for reliable actuation of various Festo solenoid valves, including series like VUVG, MEBH, MOEBH, VMPA, and CPA-SC. It operates on a 230V AC power supply at either 50 or 60 Hz. This coil is engineered for continuous operation (100% duty cycle) and features an electrical connection via a type A plug pattern as per EN 175301-803. When properly installed with a corresponding plug socket and seal, it achieves an IP65 protection rating, making it suitable for demanding industrial environments. The coil is mounted using a knurled nut and is constructed from durable materials to ensure longevity and consistent performance.
Technical Specifications:
- Festo Part Number: 30936
- Type: Solenoid coil
- Nominal Operating Voltage: 230 V AC
- Operating Frequency: 50/60 Hz
- Pick-up Power (AC): 6.5 VA
- Holding Power (AC): 4.5 VA
- Duty Cycle: 100%
- Electrical Connection: Plug pattern type A to EN 175301-803, 3-pin
- Mounting Type: With knurled nut
- Ambient Temperature Range: -20 °C to 50 °C
- Protection Class: IP65 (when mounted with plug socket and seal)
- Corrosion Resistance Classification (CRC): 2 – Moderate corrosion stress
- Permissible Voltage Fluctuation: +/- 10 %
- Permissible Frequency Fluctuation: +/- 10 %
- CE Mark: As per EU directive for EMC
- UKCA Mark: As per UK regulations for EMC, To UK RoHS regulations
- Materials (Coil): Duroplast, Copper, Steel
- Materials (Winding): Copper
- Product Weight: 55 g
Festo MSFW-230-50/60
Model：Festo MSFW-230-50/60
