Product Description
Festo DNC-32-15-PPV-A-S6-R3
The Festo DNC-32-15-PPV-A-S6-R3 is a high-performance standard cylinder designed according to ISO 15552 standards, ensuring interchangeability and a wide range of mounting accessories. This double-acting pneumatic actuator features a 32 mm piston diameter and a 15 mm stroke. The integrated adjustable pneumatic cushioning (PPV) at both ends allows for smooth, quiet, and precise deceleration into the end positions, reducing wear and vibration. Equipped with heat-resistant seals (S6), this cylinder is suitable for operating in ambient temperatures up to 120°C. Its robust construction and reliable performance make it an ideal choice for a variety of demanding industrial automation applications.
Technical Specifications:
- Stroke: 15 mm
- Piston diameter: 32 mm
- Cushioning: PPV – Pneumatic cushioning, adjustable at both ends
- Mode of operation: Double-acting
- Operating pressure: 0.4 bar to 12 bar
- Pneumatic connection: G1/8
- Standard: Conforms to ISO 15552
- Piston-rod end: Male thread
- Seals: S6 – Heat-resistant seals up to 120 °C
- Theoretical force at 6 bar, advancing: 483 N
- Theoretical force at 6 bar, retracting: 415 N
- Corrosion resistance class CRC: 2 – Moderate corrosion stress
Festo DNC-32-15-PPV-A-S6-R3
Model：Festo DNC-32-15-PPV-A-S6-R3
