Product Description
FESTO SDE3-D10D-B-WQ4-2P-M8-EX2
The FESTO SDE3-D10D-B-WQ4-2P-M8-EX2 is a high-performance, programmable pressure sensor designed for precise monitoring and control of relative pressure in pneumatic systems. It features a clear, backlit LCD display for easy reading of pressure values and status. With two independent, programmable PNP switching outputs, it offers versatile control options for various automation tasks. The sensor is ATEX-certified for use in potentially explosive atmospheres (Zone 2 and Zone 22), ensuring safety and reliability in demanding industrial environments. Its compact design with a quick-connect WQ4 pneumatic port and a standard M8 electrical plug allows for simple and fast installation.
Technical Specifications:
- Measuring Range: 0 … 10 bar
- Switching Output: 2 x PNP (Normally open / normally closed, programmable)
- Electrical Connection: M8 plug, 4-pin
- Pneumatic Connection: Push-in connector WQ4 for 4mm OD tubing
- Operating Voltage: 15 V DC to 30 V DC
- Special Feature: ATEX-certified for Zone 2 (Gas) and Zone 22 (Dust)
FESTO SDE3-D10D-B-WQ4-2P-M8-EX2
Discover the FESTO SDE3-D10D-B-WQ4-2P-M8-EX2 pressure sensor, offering a 0-10 bar range, dual PNP outputs, and M8 connectivity. This ATEX-certified sensor provides reliable pressure monitoring for hazardous industrial applications.
