Product Description

HAWE EMP31V Solenoid reversing valve

The HAWE EMP31V is a high-performance, direct-acting 3/2-way solenoid seated valve designed for manifold mounting. Engineered as a ball-type seated valve, it provides zero-leakage closure, making it ideal for applications requiring reliable load-holding and precise control of single-acting hydraulic consumers like cylinders or motors. Its robust construction ensures dependable operation even under high pressure, and the solenoid actuation allows for fast and efficient switching. This valve is a compact and reliable solution for controlling the direction of flow in a wide range of industrial and mobile hydraulic systems.

Technical Specifications:

  • Type: 3/2-way solenoid-operated seated valve
  • Design: Ball valve
  • Actuation: Solenoid, direct-acting
  • Max. Operating Pressure (p_max): 500 bar
  • Max. Flow Rate (Q_max): 25 lpm
  • Nominal Voltage: 24V DC (other voltages available)
  • Mounting: Manifold mounting
  • Hydraulic Fluid: Hydraulic oil acc. to DIN 51524 Part 1 and 2
  • Fluid Temperature Range: -20°C to +80°C
  • Leakage: Zero-leakage (leakage oil-free)

HAWE EMP31V Solenoid reversing valve

Model:HAWE EMP31V Solenoid reversing valve
