Product Description
HAWE BVG 1 R-X 24-3/8
The HAWE BVG 1 R-X 24-3/8 is a high-performance, direct solenoid-actuated 2/2-way directional seated valve. Designed as a ball valve, it provides zero-leakage shut-off, making it ideal for demanding hydraulic applications where load-holding is critical. Its compact and robust construction ensures reliability and a long service life even under high pressure. This valve is suitable for manifold mounting and is commonly used in machine tools, clamping systems, and mobile hydraulic applications requiring precise and leak-free control.
Technical Specifications:
- Valve Type: 2/2-way directional seated valve (ball valve)
- Actuation: Direct solenoid operated, 24V DC
- Max. Operating Pressure: 400 bar (5800 psi)
- Max. Flow Rate: 25 lpm (6.6 gpm)
- Connection Port Size: G 3/8″

HAWE BVG 1 R-X 24-3/8
Order the HAWE BVG 1 R-X 24-3/8, a compact 2/2-way directional seated ball valve. Features zero-leakage performance, 24V DC solenoid actuation, and a max pressure of 400 bar. Ideal for high-pressure hydraulic control systems.
